24 bit / 192 kHz

Apollo x8 Compatible with Thunderbolt 2 with optional Thunderbolt 2 to 3 adapter (not included)

Support of surround formats up to 7.1, with speaker calibration and downmix

Dual crystal clocking for low-jitter environment and clean, artifact-free recordings and stable stereo imaging

6-Core SHARC DSP for internal UAD real-time processing

4 Unison microphone preamplifiers

4 Microphone inputs: XLR

2 Hi-Z inputs: 6.3 mm jack

8 Line inputs: 6.3 mm jack

2 Monitor outputs: 6.3 mm jack

8 Line outputs: 6.3 mm jack

S/PDIF coaxial input and output

2 ADAT inputs and outputs

BNC Word clock input and output

2 Stereo headphone ports: 6.3 mm jack

2 Thunderbolt 3 ports

+48 V Phantom power

Pad

Low-cut

Phase reverse

Switch for monitor switchover

Function key can be assigned to Dim or Mono

LED Meter

Integrated talkback microphone

Support of surround formats up to 7.1, with speaker calibration and downmix

Dual crystal clocking for low-jitter environment and clean, artifact-free recordings and stable stereo imaging

For Mac/Windows

Up to 4 Apollos with Thunderbolt cascading connection

Design: 19″ / 1U

Includes external power supply and software bundle Rackmount Heritage Edition & Realtime Analog Classics Plus
